Product introduction:

This pump is suitable for pumping clean water, particularly suitable for domestic applications such as supplying water from a well. pool etc, the automatic distribution of water by surge tanks and pressure switches, gardening, and increasing of water pressure.

Component Construction:

Pump body: Cast iron, with Brass/304SS inert if request

Pump support: Cast iron, with Brass/304SS inert if requested

Molor Housing: Aluminum Alloy

Impeller: Brass

Motor Shaft: Carbon Steel(304SS if request)

Mechanical seal: Ceramic/Graphite

Operating Condition:

Liquid Temperature up to 60℃

Ambient Temperature up to 40℃

Total Suction lift up to 9m

Motor:

Single Phase220V/50Hz,110V/60Hz if requestIrsulation ClassBProduction:IP44，IP54 if requestCooling:External VentilationWthThermal ProtectorContinuous Work S1
