Component Construction:

Pump body: Cast lron

Pump support: Cast lron

Motor Housing: Aluminum Alloy

Impeller: Brass/SS

Motor Shaft: Carbon Steel(304SS if request)

Mechanical seal: Ceramic/Graphite

Operating Condition:

Liquid Temperature up to 60 ℃

Ambient Temperature up to 40 ℃

Total Suction lift up to 9m

Motor:

Single Phase220V/50Hz,110V/60Hz if request Insulation ClassB

Protection: IP44, IP54 if request

Cooling: External Ventilation With Thermal Protector Continuous Work S1
