This pump is suitable for pumping clean water, particularly suitable for domestic applications such as supplying water from a well. pool etc, the automatic distribution of water by surge tanks and pressure switch, gardening, and increasing of water pressure.

Component Construction:

Pump body: Cast iron

pump support: Cast iron

Molor Housing: Aluminum Alloy

Impeller: Brass

Motor Shaft: Carbon Steel(304SS if requested)

Mechanical seal:Ceramic/Graphite

Operating Condition:

Liquid Temperature up to 60℃

Ambient Temperature up to 40℃

Total Suction lift up to 9m

Motor:

Single Phase220V/50Hz,110V/60Hz if request insulation ClassB

Production: IP44，IP54 if request

Cooling: External Ventilation WthThermal Protector

Continuous Work S1
